6D8-24410-10 Mechanical Fuel Pump Assembly

Mechanical Fuel Pump — Compatible with select Yamaha F75B / F90B / F115A Four-Stroke

Which pump is this?

This is Yamaha 6D8-24410-10-00 (predecessor 6D8-24410-00-00), a mechanical diaphragm fuel pump. Compatible with F75B 2005–2017, F90B 2005–2017, F115A 2011–2014 and FL115A 2011–2014 in the table. It is not 68V-24410-00 (19FP004) — that pump covers earlier F75A / F80 / F90A / F100 / F115A 2000–2010 Yamaha-platform rows plus Mercury 880890. Some internal tables print 68V on the same line as 6D8; buyer fitment here is 6D8 only. F80 / F100 appear on some regional dealer pages with 6D8-24410-10; they are not in this workbook, so this page does not promise them. F150 63P is 25FP483, not this SKU.

Signs yours is due

• F75B / F90B / F115A four-stroke cranks, fires, then dies after a hot soak — mechanical pump on the block is tired.
• Fuel weep at the 6D8-24410 pump face, not a VST high-pressure module.
• Old stamp is 6D8-24410-10 or 6D8-24410-00, not 68V-24410 and not 6EK-24410.
• Not a cooling impeller.

Will it fit?

Compatible with Yamaha F75B (including F75LA / F75BETL codes 2005–2017), F90B (2005–2017), F115A (F115J / F115JA 2011–2014) and FL115A (LF115X / LF115XA 2011–2014). Serial is often not listed — match the 6D8 stamp and the exact model code. F75A / F80 / F90A / F100 on 68V is 19FP004. Later F115B / F130A 6EK-24410 is a different pump.

Engine horsepower alone does not prove fit. Match the number stamped on the pump you remove to the OEM column.

Every row is from this SKU fitment workbook (5 rows after empty-line filter). Same horsepower name shipped different pumps.

OEM and swap numbers

OEM / predecessor numbers keep the engine-brand column. Aftermarket cross-refs are numbers only.

Wrong part

• NOT 68V-24410-00 — that is 19FP004 (earlier 75–115 Yamaha-platform + Mercury 880890).
• NOT 880890T1 — Mercury number on 19FP004, not this 6D8 page.
• NOT 6EK-24410 (F115B / F130A) and NOT 63P-24410 (F150).
• NOT kit 26FFK058 (pump plus filter) as this SKU.

What ships

One complete mechanical fuel-pump assembly 6D8-24410-10 (or 00 predecessor family). No filter.

Often replaced together

68V 75–115 pump is 19FP004. F150 63P is a different SKU. Pump-plus-filter kit 26FFK058 is not this single pump.

Install

Confirm F75B / F90B / F115A / FL115A, not F75A on 68V. Photograph the pulse hose and the 6D8 stamp. Clean the pad, align the pulse hole, snug evenly. Prime, leak-check, idle on muffs. If the stamp is 68V-24410, you want 19FP004.

Frequently Asked Questions

Will this fit my Yamaha 115?

F115A / FL115A 2011–2014 in the table, yes. Earlier F115A on 68V is 19FP004. F115B 6EK is not this pump.

F80 or F100?

Not from this workbook. Do not order from an F80 / F100 cowl alone.

Is 68V-24410 the same?

No. 68V is 19FP004. This page is 6D8-24410 only.

What ships?

One 6D8-24410 pump. Not 26FFK058.

F75 2003–2004?

That early F75A band is the 68V page (19FP004), not this 6D8 F75B 2005–2017 table.

Please note

Aftermarket fuel pump by GHMarine. Not affiliated with the engine brands named above. «Compatible with», «Replaces», and cross-ref numbers mean this part is built to work like the originals listed — always confirm the stamp on the removed pump, the engine model, and the serial range before you order. This page is the pump only, not a multi-part kit.
